Produksi & Pengiriman
Waktu Produksi 15-30 Hari



High-performance P51 series bidirectional hydraulic gear pump with 104.5 cc/rev displacement, designed for heavy-duty industrial and mobile applications requiring reliable pressure up to 17 MPa.
| Seri P51 Pompa Roda Gigi Hidrolik Parameter | |
|---|---|
| Perpindahan | 104.5 cc/putaran, 21 cc/putaran, 41.8 cc/putaran, 52.3 cc/putaran, 62.7 cc/putaran, 64.6 cc/putaran |
| Tekanan Terukur | 16 MPa (2320 psi) |
| Tekanan Maksimum | 17 MPa (2465 psi) |
| Kecepatan Terukur | 2200 r/min |
| Kecepatan Maksimum | 2400 r/min |
| Putaran | Dua Arah |
| Bahan | Besi Cor |
| Struktur | Pompa Roda Gigi Eksternal |
| Versi Flens | Flange Oval-A, Lubang Pemasangan ISO-4, Flensa SAE |
| Tipe Poros | X: Spline Involute |
As a leading manufacturer of large-scale hydraulic solutions, we offer the Precision P51A646TEYR25-25 Hydraulic Gear Pump designed for versatility and durability. This P51 series component features a 104.5 cc/rev displacement and bidirectional rotation, making it ideal for complex hydraulic circuits. We provide comprehensive services including manufacturing, OEM, ODM, and customized branding to meet your specific technical requirements. Our factory direct supply ensures competitive wholesale pricing for bulk orders. We are actively seeking long-term partnerships with distributors, wholesalers, regional agents, and international traders to expand our global presence. With a rated speed of 600 r/min and a maximum pressure capacity of 17 MPa, this rugged cast iron pump is engineered for consistent performance. Partner with us for reliable factory wholesale access to premium hydraulic gear pumps and components.
