Private Label Hydraulic Valve Solutions: Customize the P80-G12-G34-OT Valve

Metode Kontrol:Buku Panduan

Spul:6 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G3/4

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P80 Katup Arah Monoblok

Ukuran kemasan:26*36*11

Kelas kotor:18.60 kg

Ketersediaan: Tersedia

1761 Pandangan Mencari Produk Ini

Private Label Hydraulic Valve Solutions: Customize the P80-G12-G34-OT Valve

Private Label Hydraulic Valve Solutions: Customize the P80-G12-G34-OT Valve

Private Label Hydraulic Valve Solutions: Customize the P80-G12-G34-OT Valve drawing image

Introducing our Private Label Hydraulic Valve Solutions, offering customizable P80-G12-G34-OT valves tailored to your specific requirements. With manual control, a 6-section monoblock design, and exceptional performance parameters, these valves are ideal for various applications in material handling, construction, agriculture, and industrial vehicles.

Seri P80 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 80 L/menit (21,2 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Keluar G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Ukuran Port G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

Our Private Label Hydraulic Valve Solutions empower you with the flexibility to customize the P80-G12-G34-OT valve to perfectly match your unique specifications. Enjoy the benefits of OEM and ODM capabilities, allowing you to create valves that seamlessly integrate with your existing systems and branding. With a rated flow of 80 L/min, maximum pressure of 250 bar, and operating viscosity range of 15 - 75 mm²/s, these valves are engineered to excel in demanding hydraulic applications. They operate reliably within an ambient temperature range of -40°C to +80°C and feature a robust 6-spool design to handle multiple functions simultaneously. Whether you need valves for telehandlers, forklifts, motor graders, excavators, skid steer loaders, wheel loaders, backhoe loaders, tractors, front-end loaders, or harvesters, our Private Label Hydraulic Valves offer tailored solutions that meet your precise requirements.
