SD5-G38 Hydraulic Valve: The Ultimate Guide for Smooth Operation

Metode Kontrol:Buku Panduan

Spul:1 Spool

Aliran Terukur:45 L/menit (11,8 US gpm)

Tekanan Maksimum:315 bar (4600 psi)

Port Masuk:G3/8

Port Keluar:G3/8

Ukuran Port:G3/8

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri SD5 Katup Arah Monoblok

Ukuran kemasan:23*20*12

Kelas kotor:3.80 kg

Ketersediaan: Tersedia

1087 Pandangan Mencari Produk Ini

SD5-G38 Hydraulic Valve: The Ultimate Guide for Smooth Operation

SD5-G38 Hydraulic Valve: The Ultimate Guide for Smooth Operation

SD5-G38 Hydraulic Valve: The Ultimate Guide for Smooth Operation drawing image

The SD5-G38 Adjustable Pressure Controller is a reliable and durable hydraulic valve designed for smooth operation in a wide range of applications. It offers precise pressure control, high flow rate, and robust construction, making it ideal for use in construction equipment, material handling, agriculture, and industrial vehicles.

Seri SD5 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +60°C (-40°F hingga +140°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 40 L/menit (10,5 US gpm)
Tekanan Maksimum 305 bar (4400 psi)
Port Masuk G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8, G1-1/2
Port Keluar G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8
Ukuran Port G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8

The SD5-G38 Adjustable Pressure Controller is a high-performance hydraulic valve designed for demanding applications. Its monoblock construction provides exceptional strength and durability, while its manual control method allows for precise pressure adjustments. With a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 305 bar (4400 psi), this valve is suitable for a wide range of hydraulic systems. Its wide operating viscosity range and temperature range ensure reliable performance in various environments. The SD5-G38 is designed for use in a variety of applications, including telehandlers, forklifts, cranes, excavators, loaders, tractors, harvesters, and other industrial vehicles. Its robust construction and high performance make it the perfect choice for demanding applications requiring precise pressure control and reliable operation.
