SD8 Series 3 Spool Sectional Directional Hydraulic Valve

Metode Kontrol:Buku Panduan

Spul:3 Spool

Aliran Terukur:90 L/menit (23,8 US gpm)

Tekanan Maksimum:315 bar (4600 psi)

Port Masuk:G1/2

Port Keluar:G3/4

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Kran Arah Bagian

Seri Produk:Seri SD8 Kran Arah Bagian

Ukuran kemasan:26*36*16

Kelas kotor:14.50 kg

Ketersediaan: Tersedia

97 Pandangan Mencari Produk Ini

SD8 Series 3 Spool Sectional Directional Hydraulic Valve

SD8 Series 3 Spool Sectional Directional Hydraulic Valve

SD8 Series 3 Spool Sectional Directional Hydraulic Valve drawing image

The SD8 Series 3 Spool Sectional Directional Hydraulic Valve is a high-performance manual control solution designed for versatile applications in agriculture, construction, and material handling. Featuring a rated flow of 80 L/min and a maximum pressure capacity of 250 bar, this valve provides precise fluid management for machinery like mini-excavators, tractors, and forklifts.

Seri SD8 Kran Arah Bagian Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool, 8 Spool, 9 Spool, 10 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup penampang
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian, 8 Bagian, 9 Bagian, 10 Bagian
Kisaran Viskositas Operasional 12 - 400 mm²/dt (12 cSt hingga 400 cSt)
Aliran Terukur 90 L/menit (23,8 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, SAE 10
Port Keluar G1/2, G3/4, SAE 10, 3/4 NPT
Ukuran Port G1/2, SAE 10

As a leading manufacturer of premium hydraulic products, we offer the SD8 Series 3 Spool Sectional Directional Hydraulic Valve, engineered for durability and precision. This manual control valve supports a rated flow of 80 L/min (21.2 US gpm) and operates efficiently under pressures up to 250 bar (3600 psi), making it suitable for front-end loaders, skid steers, and wood splitters. Our factory provides comprehensive solutions including OEM, ODM, and customized manufacturing to meet specific technical requirements. We specialize in bulk wholesale and factory-direct supply for global markets. We are actively seeking long-term partnerships with professional distributors, wholesalers, agents, and traders. Whether you need private labeling (OEM) or specific port configurations (G1/2 inlet, G3/4 outlet), our production facility ensures reliable quality and consistent supply for industrial and mobile hydraulic sectors. Enhance your inventory with our versatile SD8 series valves designed for backhoes, telehandlers, and harvesters.
