Sectional Hydraulic Control Valve HSV20 Manual 1 Spool Type

Metode Kontrol:Buku Panduan

Spul:1 Spool

Aliran Terukur:75 L/menit (19,8 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:SAE 12

Port Keluar:SAE 12

Ukuran Port:SAE 10

Merek:BXHS

Tipe Produk:Kran Arah Bagian

Seri Produk:Seri HSV20 Kran Arah Bagian

Ukuran kemasan:34*27*18

Kelas kotor:13.00 kg

Ketersediaan: Tersedia

102 Pandangan Mencari Produk Ini

Sectional Hydraulic Control Valve HSV20 Manual 1 Spool Type

Sectional Hydraulic Control Valve HSV20 Manual 1 Spool Type

Sectional Hydraulic Control Valve HSV20 Manual 1 Spool Type drawing image

The HSV20 Series is a robust 1-spool sectional hydraulic control valve designed for precise fluid power management. With a 75 L/min flow capacity and 250 bar pressure rating, it serves as a reliable solution for construction, agricultural, and material handling equipment, providing excellent performance for demanding mobile applications.

Seri HSV20 Kran Arah Bagian Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Listrik, Manual dan Joystick, Manual dan Elektro-hidraulik
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool, 8 Spool, 9 Spool, 10 Spool, 11 Spool, 12 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup penampang
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian, 8 Bagian, 9 Bagian, 10 Bagian, 11 Bagian, 12 Bagian
Kisaran Viskositas Operasional 12 - 400 mm²/dt (12 cSt hingga 400 cSt)
Aliran Terukur 75 L/menit (19,8 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/4, SAE 12
Port Keluar G3/4, SAE 12
Ukuran Port G1/2, SAE 10

As a leading manufacturer of high-performance hydraulic components, we offer the HSV20 Series sectional control valve tailored for diverse industrial and mobile machinery. Engineered for efficiency and durability, this 1-spool manual valve is ideal for equipment like tractors, front-end loaders, wood splitters, and forklifts. We specialize in comprehensive manufacturing services including OEM, private labeling, and custom engineering to meet specific technical requirements. Working with us provides direct access to competitive factory pricing, ensuring robust margins for your distribution business. We are actively seeking long-term cooperation with global distributors, wholesalers, trade companies, and agents. Benefit from our large-scale production capacity, rigorous quality control, and professional technical support. Contact our sales team today to discuss bulk purchasing, customized branding solutions, or to join our network of global partners.
