Solenoid Hydraulic Valve | P40-DKL | Contact Us for Specifications

Metode Kontrol:Selenoid

Spul:3 Spool

Aliran Terukur:40 L/menit (10,5 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G1/2

Ukuran Port:G3/8

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:P40-DKL Series Katup Arah Monoblok

Ukuran kemasan:31*21*17

Kelas kotor:9.00 kg

Ketersediaan: Tersedia

1294 Pandangan Mencari Produk Ini

Solenoid Hydraulic Valve | P40-DKL | Contact Us for Specifications

Solenoid Hydraulic Valve | P40-DKL | Contact Us for Specifications

Solenoid Hydraulic Valve | P40-DKL | Contact Us for Specifications drawing image

The P40-DKL series is a 3-section monoblock solenoid valve designed for heavy-duty applications in material handling, construction, and agriculture. With a rated flow of 40 L/min and a max pressure of 250 bar, this valve is ideal for controlling hydraulic actuators in a variety of equipment, including telehandlers, forklifts, and excavators.

P40-DKL Series Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Aliran Terukur 40 L/menit (10,5 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Keluar G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Ukuran Port G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Tipe Struktur Katup monoblok
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)

This P40-DKL series tractor 3-point control valve features a solenoid actuation method for precise control of hydraulic functions. Its 3-section design provides separate control of multiple hydraulic circuits. The valve is constructed with a robust monoblock design, ensuring long-lasting durability in demanding applications. With a rated flow of 40 L/min and a max pressure of 250 bar, this valve is suitable for a wide range of equipment in industries such as material handling, construction, and agriculture. The P40-DKL series is compatible with a variety of equipment, including telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
