Source Directly & Save: SD25 Valves from the Factory Producer

Metode Kontrol:Buku Panduan

Spul:1 Spool

Aliran Terukur:240 L/menit (63,4 US gpm)

Tekanan Maksimum:315 bar (4600 psi)

Port Masuk:G1

Port Keluar:G1-1/4

Ukuran Port:G1

Merek:BXHS

Tipe Produk:Kran Arah Bagian

Seri Produk:Seri SD25 Kran Arah Bagian

Ukuran kemasan:30*45*20

Kelas kotor:28.50 kg

Ketersediaan: Tersedia

1159 Pandangan Mencari Produk Ini

Source Directly & Save: SD25 Valves from the Factory Producer

Source Directly & Save: SD25 Valves from the Factory Producer

Source Directly & Save: SD25 Valves from the Factory Producer drawing image

Our SD25 series two spool hydraulic control valve is a high-performance, reliable option for various applications, including construction equipment, material handling, agriculture, and industrial vehicles. This manual control valve offers a rated flow of 240 L/min (63.4 US gpm) and a max pressure of 315 bar (4600 psi). Designed for durability and efficiency, it is suitable for demanding environments.

Seri SD25 Kran Arah Bagian Parameter
Metode Kontrol Buku Panduan, Elektro-hidraulik, Hidraulis
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup penampang
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian, 8 Bagian, 9 Bagian, 10 Bagian
Kisaran Viskositas Operasional 12 - 400 mm²/dt (12 cSt hingga 400 cSt)
Aliran Terukur 240 L/menit (63,4 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1, SAE 16
Port Keluar G1-1/4, SAE 16
Ukuran Port G1, G1-1/4, SAE 12

The SD25 series two spool hydraulic control valve is a reliable and efficient solution for various applications. Manufactured directly from our factory, we offer wholesale pricing and direct supply, ensuring competitive pricing and high-quality products. This monoblock valve features manual control, a rated flow of 240 L/min (63.4 US gpm), and a maximum pressure of 315 bar (4600 psi). It operates within a viscosity range of 12 - 400 mm²/s (12 cSt to 400 cSt) and is suitable for ambient temperatures ranging from -40°C to +80°C (-40°F to +176°F). Designed for various applications in material handling, construction and earth moving, agriculture, and industrial vehicles, this valve is perfect for telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, and wheel loaders. Choose our SD25 series two spool hydraulic control valve for reliable performance and cost-effectiveness, directly from the factory.
