Our P80 Cable Directional Control Valves are designed for reliable and efficient operation in a wide range of hydraulic systems. With a rated flow of 80 L/min and a maximum pressure of 250 bar, these valves provide precise control and durability. Their monoblock construction ensures a compact and robust design, while the cable control method offers smooth and responsive operation. The wide operating viscosity range (15 - 75 mm²/s) and ambient temperature range (-40°C to +80°C) make these valves suitable for various applications, including material handling, construction, agriculture, and industrial vehicles.
| Seri P80 Katup Arah Monoblok Parameter | |
|---|---|
| Metode Kontrol | Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup monoblok |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Aliran Terukur | 80 L/menit (21,2 US gpm) |
| Tekanan Maksimum | 315 bar (4600 psi) |
| Port Masuk | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Port Keluar | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Ukuran Port | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT |
Our P80 Cable Directional Control Valves feature:
* **Control Method:** Cable for smooth and precise operation
* **Section:** 3-section design provides versatility and flexibility
* **Structure Type:** Monoblock construction for compactness and durability
* **Rated Flow:** 80 L/min (21.2 US gpm) for efficient fluid flow
* **Max Pressure:** 250 bar (3600 psi) for demanding applications
* **Operating Viscosity Range:** 15 - 75 mm²/s (15 cSt to 75 cSt) for use with a variety of fluids
* **Ambient Temperature Range:** -40°C to +80°C (-40°F to +176°F) for reliable operation in harsh environments
* **Spool:** 3 Spool configuration for precise flow control
* **Series:** Part of the P80 Series, known for its reliability and performance
* **Application Area:** Ideal for material handling, construction, agriculture, and industrial vehicles, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders
Our P80 Cable Directional Control Valves are manufactured using high-quality materials and undergo rigorous testing to ensure optimal performance and longevity. They are backed by our commitment to customer satisfaction and come with a comprehensive warranty for added peace of mind.
