Produksi & Pengiriman
Waktu Produksi 15-30 Hari
996 Pandangan Mencari Produk Ini
The 7-Spool Hydraulic Valve from our P40 Series offers a compact and reliable solution for a wide range of applications. This monoblock valve features manual control, a rated flow of 40 L/min, and a maximum pressure of 250 bar. We provide OEM, ODM, private label, and customization services to tailor the valve to your specific needs.
| Seri P40 Katup Arah Monoblok Parameter | |
|---|---|
| Metode Kontrol | Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel |
| Spul | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Kisaran Suhu Sekitar | -40°C hingga +80°C (-40°F hingga +176°F) |
| Tipe Struktur | Katup monoblok |
| Bagian | 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian |
| Kisaran Viskositas Operasional | 15 - 75 mm²/dt (15 cSt hingga 75 cSt) |
| Aliran Terukur | 40 L/menit (10,5 US gpm) |
| Tekanan Maksimum | 250 bar (3600 psi) |
| Port Masuk | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Port Keluar | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Ukuran Port | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
This 7-Spool Hydraulic Valve is designed for demanding applications in industries such as material handling, construction, and agriculture. It features a compact monoblock design, manual control, and a rated flow of 40 L/min. The valve can handle pressures up to 250 bar and is suitable for a wide range of operating temperatures. We offer comprehensive OEM and ODM services, including customization, private labeling, and manufacturing. This allows us to tailor the valve to your specific requirements and provide you with a cost-effective solution. Contact us today to discuss your project and explore how our 7-Spool Hydraulic Valve can meet your needs.
