Top Manufacturer of P80-G34-5OT 5 Spool Directional Valve

Metode Kontrol:Buku Panduan

Spul:5 Spool

Aliran Terukur:80 L/menit (21,2 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G3/4

Port Keluar:G3/4

Ukuran Port:G3/4

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P80 Katup Arah Monoblok

Ukuran kemasan:26*30*11

Kelas kotor:16.00 kg

Ketersediaan: Tersedia

1148 Pandangan Mencari Produk Ini

Top Manufacturer of P80-G34-5OT 5 Spool Directional Valve

Top Manufacturer of P80-G34-5OT 5 Spool Directional Valve

Top Manufacturer of P80-G34-5OT 5 Spool Directional Valve drawing image

The P80-G34-5OT 5 Spool Directional Valve is a heavy-duty, high-performance hydraulic valve designed for use in a wide range of construction, agricultural, and industrial applications. This 5-section monoblock valve features manual control, 80 L/min flow rate, and 250 bar maximum pressure, making it ideal for demanding tasks.

Seri P80 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Manual dan Joystick
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 80 L/menit (21,2 US gpm)
Tekanan Maksimum 315 bar (4600 psi)
Port Masuk G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port Keluar G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Ukuran Port G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

This P80 series auxiliary hydraulic valve is a top-of-the-line product manufactured for global markets. It is a 5-spool directional valve with manual control, designed for use in a variety of applications, including material handling, construction and earth moving, agriculture, and industrial vehicles. The valve is a monoblock structure with a rated flow of 80 L/min and a maximum pressure of 250 bar. It is suitable for a wide range of operating viscosity, from 15 to 75 mm²/s, and can withstand ambient temperatures from -40°C to +80°C. The valve is designed for use in a variety of applications, including telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, dumpers, face drill rigs, concrete boom pumps, pave rollers, rotary drilling, crushers, and stone cutters. This high-quality valve offers durability, reliability, and high performance, making it an excellent choice for demanding applications.
