White Label Solutions for P40 Pneumatic 2 Spool Monoblock Directional Valve

Metode Kontrol:Pneumatik

Spul:2 Spool

Aliran Terukur:40 L/menit (10,5 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G1/2

Ukuran Port:G3/8

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P40 Katup Arah Monoblok

Ukuran kemasan:23*18*13

Kelas kotor:6.00 kg

Ketersediaan: Tersedia

1078 Pandangan Mencari Produk Ini

White Label Solutions for P40 Pneumatic 2 Spool Monoblock Directional Valve

White Label Solutions for P40 Pneumatic 2 Spool Monoblock Directional Valve

White Label Solutions for P40 Pneumatic 2 Spool Monoblock Directional Valve drawing image

Introducing our premium White Label Solutions for P40 Pneumatic 2 Spool Monoblock Directional Valve, meticulously engineered to meet the diverse needs of global markets. This exceptional valve boasts a rated flow of 40 L/min (10.5 US gpm) and withstands pressure up to 250 bar (3600 psi), making it ideal for demanding applications in various industries.

Seri P40 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 40 L/menit (10,5 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Keluar G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Ukuran Port G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

Our P40 Series Pneumatic Directional Valve stands out with its exceptional performance and versatility. With its 2 spool design and monoblock structure, this valve ensures precise control and durability. Operating seamlessly within a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and ambient temperatures ranging from -40°C to +80°C (-40°F to +176°F), it adapts effortlessly to challenging environments. This valve finds its application in diverse industries, including material handling, construction and earth moving, agriculture, and industrial vehicles, making it an indispensable component for a wide range of machinery. As a leading manufacturer, we offer unparalleled OEM, private label, and custom solutions to cater to your specific requirements. Our commitment to quality and customer satisfaction drives us to provide tailored products that meet your unique demands.
