Wholesale P40Q-OT Pneumatic 1 Spool Monoblock Valve from Factory

Metode Kontrol:Pneumatik

Spul:1 Spool

Aliran Terukur:40 L/menit (10,5 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G1/2

Ukuran Port:G3/8

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P40 Katup Arah Monoblok

Ukuran kemasan:29*16*11

Kelas kotor:3.50 kg

Ketersediaan: Tersedia

72 Pandangan Mencari Produk Ini

Wholesale P40Q-OT Pneumatic 1 Spool Monoblock Valve from Factory

Wholesale P40Q-OT Pneumatic 1 Spool Monoblock Valve from Factory

Wholesale P40Q-OT Pneumatic 1 Spool Monoblock Valve from Factory drawing image

The P40Q-OT is a high-performance 1-spool pneumatic monoblock directional control valve designed for mobile applications. Featuring a rated flow of 40 L/min and capable of handling pressures up to 250 bar, this P40 series valve provides reliable pneumatic actuation for machinery in agriculture, construction, and material handling sectors.

Seri P40 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 40 L/menit (10,5 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Keluar G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Ukuran Port G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

As a prominent hydraulic product manufacturer, we offer the P40Q-OT Pneumatic 1 Spool Monoblock Valve for global distribution. This P40 series directional valve is engineered for heavy-duty applications including forklifts, mini-excavators, and tractors. With a flow rate of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi), it ensures efficient fluid power control. Our factory provides comprehensive manufacturing services including OEM, ODM, and custom branding (Private Labeling) to meet specific market requirements. We specialize in factory wholesale and are actively seeking long-term partnerships with distributors, wholesalers, agents, and traders worldwide. Whether you need customized hydraulic solutions for wood splitters or bulk supplies for industrial vehicle fleets, our factory supply chain guarantees consistent quality and competitive wholesale pricing. This pneumatic spool valve features G1/2 inlet/outlet ports and G3/8 working ports, making it highly compatible with various hydraulic systems in sweepers, aerial platforms, and skid steer loaders.
