Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT

Metode Kontrol:Buku Panduan

Spul:1 Spool

Aliran Terukur:40 L/menit (10,5 US gpm)

Tekanan Maksimum:250 bar (3600 psi)

Port Masuk:G1/2

Port Keluar:G1/2

Ukuran Port:G1/2

Merek:BXHS

Tipe Produk:Katup Arah Monoblok

Seri Produk:Seri P40 Katup Arah Monoblok

Ukuran kemasan:23*16*11

Kelas kotor:3.00 kg

Ketersediaan: Tersedia

1030 Pandangan Mencari Produk Ini

Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT

Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT

Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT drawing image

Introducing Your Hydraulic Partner: a leading provider of OEM, ODM, and White Label services for hydraulic products. Our expertise lies in developing and manufacturing high-quality hydraulic components and systems tailored to meet your specific needs. Partner with us to elevate your product offerings with our exceptional manufacturing capabilities and commitment to innovation.

Seri P40 Katup Arah Monoblok Parameter
Metode Kontrol Buku Panduan, Pneumatik, Elektro-pneumatik, Elektro-hidraulik, Selenoid, Hidraulis, Hidraulik dan Manual, Kabel, Stik Kontrol, Selenoid dan Joystick, Manual dan Joystick, Solenoid dan Kabel
Spul 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Kisaran Suhu Sekitar -40°C hingga +80°C (-40°F hingga +176°F)
Tipe Struktur Katup monoblok
Bagian 1 Bagian, 2 Bagian, 3 Bagian, 4 Bagian, 5 Bagian, 6 Bagian, 7 Bagian
Kisaran Viskositas Operasional 15 - 75 mm²/dt (15 cSt hingga 75 cSt)
Aliran Terukur 40 L/menit (10,5 US gpm)
Tekanan Maksimum 250 bar (3600 psi)
Port Masuk G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port Keluar G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Ukuran Port G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

Our P40-G12-1OT monoblock valve is a prime example of our engineering prowess. Designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles, this valve delivers exceptional performance with a rated flow of 40 L/min, a maximum pressure of 250 bar, and an operating viscosity range of 15 - 75 mm²/s. Its robust construction ensures reliable operation in harsh environments with an ambient temperature range of -40°C to +80°C. Whether you require OEM manufacturing, ODM customization, or White Label branding, we have the expertise and infrastructure to fulfill your requirements. Our commitment to quality and customer satisfaction sets us apart, making us the ideal choice for businesses seeking a reliable hydraulic partner.
